Dynacord Dynacord C1800FDI-US Amplifier

Dynacord C1800FDI-US Amplifier

by Dynacord
SKU C1800FDI-US
Save $313.00 Save $313.00
$1,542.00
$1,542.00 - $1,542.00
$1,542.00
$1,229.00
$1,229.00 - $1,229.00
$1,229.00

Need more info before you place your order?

Questions about equipment compatibility or shipping times? Contact us, we can help!

Request a quote

Product Information

Dynacord C1800FDi DSP 2 x 950 W Power Amplifier for fixed install applications.

Product details:

  • Professional Installation DSP amplifier
  • Fully integrated professional speaker processing with FIR Drive technology
  • Market leading acoustic performance and rock solid reliability
  • Intuitive system control software, makes setup and control easy
  • C1800FDI-US User Manual
  • Color: Black
  • Dimensions (W x H x D), 17.2" x 3.4" x 18.2"
  • Weight 15.2 kg (33.5 lb)

DYNACORD C Series amplifiers are dedicated installation DSP amplifiers optimized for 24/7 operation. Integrated digital signal processing provides access to professional speaker processing with FIR Drive technology. C Series amplifier utilize Class A/B resp.

Class H topologies, which provide market-leading acoustic performance and reliability. The connectivity is optimized for the needs of fixed install applications. For low cost of ownership a power saving standby mode is available. A front panel LC display allows local control and supervision of the amplifier. An intuitive system control software allows fast system setup, flexible system control and comprehensive supervision.

For over 70 years, Dynacord has designed and engineered professional audio systems – products that offer unparalleled performance and premium quality, the perfect balance of power and precision.

Specifications:

Maximum RMS Voltage Swing THD = 1%, 1 kHz 65.1 V
Voltage Gain Ref.1 kHz 32.0 dB
THD at 600 W/4 ΩMBW = 80 kHz, 1kHz < 0.05%
IMD-SMPTE, 60 Hz, 7 kHz < 0.1%
DIM30, 3.15 kHz, 15 kHz < 0.05%
Maximum Input Level +21 dBu
Crosstalk ref. 1 kHz, at 100W/4 Ω < -80 dB
Frequency Response, ref. 1 kHz Frequency Response, ref. 1 kHz
Frequency Response, ref. 1 kHz 20 k Ω
Signal to Noise Ratio Amplifier, A-weighted, ref to Max. Output Power@ 8 Ω >105 dB
Output Noise, A-weighted < -68 dBu
Output Stage Topology Class AB
Power Requirements 240 V, 230 V, 120 V or 100 V; 50 Hz to 60 Hz (factory configured)
Power Consumption ⅛ Maximum Output Power @ 4 Ω 700 W
Mains Fuse 240 V/230 V: T12AH; 120 V/100 V: T25AH
Protection Audio limiters, high temperature, DC, HF, Back-EMF, Peak current limiters, In rush current limiters, Turn on delay
Cooling Front-to-rear, 3-stage-fans
Ambient Temperature Limits +5°C to +40°C (40°F to +105°F)
Safety Class I
Color Black
Dimensions (W x H x D), mm 483 x 88 x 462.4
Weight 15.2 kg (33.5 lb)
Remote Power ON/GPIO Power remote via switch, delay time selectable Floating relay contacts (show protect mode) Inputs for preset selection
Signal Processing FIR filters, audio limiters, output and array** delay, 10-band** user PEQ, 5-band array PEQ** per channel, load impedance
Remote Control SONICUE sound system software **
Accessories RMK15 (rear rack mount kit)
